Network Interfaces
Standard: 1000Base-T/100Base-TX/10Base-T Ethernet, USB 2.0 Type A (3 Ports), SD Slot on Operation Panel
Option: IEEE1284/ECP, IEEE802.11a/b/g/n, USB 2.0 Type B
Network Protocol Support
TCP/IP (IPv4, IPv6)
Network/OS
Windows Vista/7/8/8.1/Server 2008/Server 2008R2/Server2012/Server2012R2
Unix; Sun Solaris, HP-UX, SCO OpenServer, RedHat Linux, IBM AIX
Mac OS X v.10.7 or later, SAP R/3, IBM iSeries AS/400-using OS/400 Host Print Transform
Utilities
Device Manager NX Series, Web Image Monitor, @Remote
Document Server Specifications (Standard)
Max. Stored Documents
3,000
Max. Pages/Document
2,000
Max. Page Capacity
9,000
Max. Number of Folders
200
Scanner Specifications (Standard)
Scanner Resolution
B&W and FC scanning at 100 – 600 dpi, Up to 1200 dpi for TWAIN scanning
Scanning Speed (B&W & Color LTR)
54 ipm (200 dpi/300 dpi)
Scan Area
11.7" x 17" (297 – 432 mm)
Compression Method
B&W TIFF: MH, MR, MMR, JBIG2
Color: JPEG
Supported File Formats
Single/Multi-Page TIFF, PDF, High Compression PDF & PDF/A, Single Page JPEG
Scan Modes
Scan-to-Email (with LDAP support)
Scan-to-Folder (SMB/FTP)
Scan-to-URL
Scan-to-Media (USB/SD Card)
Network TWAIN Scanning
Facsimile Specifications (Optional)
Type
ITU-T (CCITT) G3
Circuit
PSTN, PBX
Resolution
200 x 100 dpi, 200 x 200 dpi, 400 x 400 dpi (with optional SAF memory)
Modem Speed
33.6K – 2,400 bps w/Auto Fallback
Compression Method
MH, MR, MMR, JBIG
Transmission Speed
G3: Approximately 2 seconds/page (JBIG)
Scanning Speed
Up to 58 spm — standard and detail modes (A4)
Auto Dialing
2,000 Quick/Speed Dial numbers; 100 Group Dial numbers
Memory Capacity (SAF)
Standard: 4 MB (approx. 320 pages)
Optional: 64 MB (approx. 4,800 pages) with optional SAF memory
Security Features (Standard)
DataOverwriteSecurity System (DOSS), HDD Encryption, User Codes, SNMP v3 Support, Encryption, Locked Print, User Authentication, 802.1x Wired Authentication, Quota Setting/Account Limit, Digitally Signed PDF, and more
